LS-653 Phenyl Siloxane
CAS NO.: 3390-61-2

Name: LS-653 Phenyl Siloxane
Brand: Nanjing Silfluo New Material Co., Ltd.
Availability: InStock

Silfluo LS-653 is 1,3,5-Trimethyl-1,1,3,5,5-pentaphenyltrisiloxane, a pentaphenyl-modified trisiloxane fluid.

The molecule contains five phenyl groups and three methyl groups on a linear three-unit Si–O backbone.

Higher phenyl content relative to LS-644 (tetraphenyl) gives a lower vapor pressure and higher boiling point, extending the achievable vacuum range.

Used as working fluid in ultra-high-vacuum diffusion pumps, and as heat transfer or dielectric base fluid in high-temperature or radiation-exposed environments.

Performance equivalent to Dow DC-705 and Shin-Etsu HIVAC-F5.

Where to buy CAS NO.: 3390-61-2 PDF Download

Typical Technical Properties of LS-653 Phenyl Siloxane

Silfluo Code:	LS-653
Chemical Name: Synonyms:	1,1,3,5,5-Pentaphenyl-1,3,5-Trimethylsiloxane 1,3,5-Trimethyl-1,1,3,5,5-pentaphenyltrisiloxane
CAS No.: EINECS No.:	3390-61-2 222-222-9
Molecular Formula:	C₃₃H₃₄O₂Si₃
Molecular Weight:	546.88
Appearance:	Colorless transparent liquid
Purity (by GC,%):	98.0 min
Density (25°C):	1.09
Refractive Index (nD 25°C):	1.58
Boiling Point:	245°C(0.5mmHg)
Flash Point:	243°C

Applications of LS-653 Phenyl Siloxane

1. Ultra-high-vacuum diffusion pumps

Used as working fluid in UHV diffusion pumps for electron microscopes, mass spectrometers, and particle accelerators.

2. Space simulation and aerospace vacuum systems

Used in large-scale space simulation chambers and vacuum metallurgy systems during high-temperature thermal cycling and degassing.

3. Semiconductor and display thin-film deposition

Used in PVD.CVD sputtering and thermal evaporation vacuum chambers for optical coating, semiconductor, and OLED panel manufacturing.

4. High-temperature heat transfer and dielectric fluids

Used as heat transfer fluid and dielectric coolant in electronic modules and instruments under severe thermal or radiation exposure.

Packing of LS-653 Phenyl Siloxane

In 1kg fluorinated bottle, 25kg pail and 200kg drum.

Safety and Storage of LS-653 Phenyl Siloxane

Keep in a cool, dry, and well-ventilated environment, strictly avoiding direct sunlight, heat, and ignition sources. The shelf life is 12 months from the date of manufacture when stored in original unopened containers. Classified as a non-hazardous substance for transport and handling. Storage beyond the shelf life does not necessarily mean the product is unusable; however, the properties required for the intended use must be thoroughly checked for quality assurance reasons prior to application.
